Help with adding FX effect and sanity loss on use to tools!

[Doodle Monster]

Hi! So, I wanted to do something similar with the shadow tools with a fx animation and sanity drain. I did a little digging in dst’s prefabs but I could not find a component for on item use.

Basically I want to spawn a FX effect on the object being chopped/mined and drain sanity when the item is used for each use.

I have basic knowledge of Lua. with functions and variables, still trying to learn returns and such

Any help would be really awesome!


[Merkyrrie]

Tools don't have a dedicated on hit function in their component to make things easier like weapons do, but there is a push event when a character does a "work" action, which includes mining, chopping, and digging. You can call a listenforevent for this event in the onequip function of the tools.

local function OnDoingWork(owner, data)
    -- From Wolfgang's prefab
    if data ~= nil and data.target ~= nil then
		local workable = data.target.components.workable
		if workable ~= nil then
			local work_action = workable:GetWorkAction()
			if work_action ~= nil then
                -- Spawn FX and lower sanity code would go here
			end
		end
    end
end

local function onequip(inst, owner)
	-- The usual onequip code here too
    owner:ListenForEvent("working", OnDoingWork) -- "owner" instead of "inst" because the player's instance is what the event is being pushed to
end

local function onunequip(inst, owner)
	-- The usual onunequip code here too
    owner:RemoveEventCallback("working", OnDoingWork) -- This stops listening for the event when the item is unequipped.
end



[Doodle Monster]

Thanks for the help! Do I need to specify the location I want the FX to spawn? I'm trying to make it spawn ontop of the object being choped/mined

[Doodle Monster]

Okay, So I put everything together; not sure if I did the sanity drain correctly. As soon as I craft the Axe my game crashes and throws this error



My function looks like this



local function OnDoingWork(owner, data)

    -- From Wolfgang's prefab

    if data ~= nil and data.target ~= nil then

        local workable = data.target.components.workable

        if workable ~= nil then

            local work_action = workable:GetWorkAction()

            if work_action ~= nil then



                local fx_prefab = "shadow_despawn" and



                    owner.components.sanity:DoDelta(-.5 * TUNING.BATBAT_DRAIN)



                    if fx_prefab ~= nil then

                        local fx = SpawnPrefab(fx_prefab)

                        local x, y, z = target.Transform:GetWorldPosition()

                        local radius = target:GetPhysicsRadius(.5)

                        local angle = (inst.Transform:GetRotation() - 90) * DEGREES

                        fx.Transform:SetPosition(x + math.sin(angle) * radius, 0, z + math.cos(angle) * radius)

                    end

                -- Spawn FX and lower sanity code would go here

            end

        end

    end

end

[Doodle Monster]

My onequpit and onunequpit functions look like this

local function OnEquip(inst, owner)

    -- This will override symbol "swap_body" of the equipping player with your custom build symbol.

    -- Here's what this function is overriding:

    -- owner.AnimState:OverrideSymbol(Player's_symbol, Your_build(*.zip_filename), Symbol_from_your_build(name_of_subfolder_with_art)

    owner.AnimState:OverrideSymbol("swap_object", "woven_axe", "swap_object")



    owner:ListenForEvent("working", OnDoingWork) -- "owner" instead of "inst" because the player's instance is what the event is being pushed to



    -- Players have 2 left arms - one of them is hidden when we are not holding an item and vice versa.

    -- Since we want to show an item on equip - hide ARM_normal and show ARM_carry.

    owner.AnimState:Show("ARM_carry")

    owner.AnimState:Hide("ARM_normal")

end



local function OnUnequip(inst, owner)

    owner.AnimState:Hide("ARM_carry")

    owner.AnimState:Show("ARM_normal")



    owner:RemoveEventCallback("working", OnDoingWork) -- This stops listening for the event when the item is unequipped.

end



Edited April 11, 2025 by Doodle Monster

[Doodle Monster]

@Merkyrrie Sorry for the ping! Just wanted to make sure this gets to you



Edited April 11, 2025 by Doodle Monster

[Doodle Monster]

I'm not sure why it's saying the varible isn't defined, I'm assumeing I have to define it further up maybe with the wolfgang file

[Doodle Monster]

I did find this further down in the wolfgang file;

but it looks like I already have it in the onequpit and unequpit so I'm not sure what is going on

inst:ListenForEvent("working", OnDoingWork)

[Merkyrrie]

17 hours ago, Doodle Monster said:

Okay, So I put everything together; not sure if I did the sanity drain correctly. As soon as I craft the Axe my game crashes and throws this error





My function looks like this



local function OnDoingWork(owner, data)

    -- From Wolfgang's prefab

    if data ~= nil and data.target ~= nil then

        local workable = data.target.components.workable

        if workable ~= nil then

            local work_action = workable:GetWorkAction()

            if work_action ~= nil then



                local fx_prefab = "shadow_despawn" and



                    owner.components.sanity:DoDelta(-.5 * TUNING.BATBAT_DRAIN)



                    if fx_prefab ~= nil then

                        local fx = SpawnPrefab(fx_prefab)

                        local x, y, z = target.Transform:GetWorldPosition()

                        local radius = target:GetPhysicsRadius(.5)

                        local angle = (inst.Transform:GetRotation() - 90) * DEGREES

                        fx.Transform:SetPosition(x + math.sin(angle) * radius, 0, z + math.cos(angle) * radius)

                    end

                -- Spawn FX and lower sanity code would go here

            end

        end

    end

end

Is the OnDoingWork function above or below the onequip and onunequip functions?

local functions should generally be above anything that is calling them

Edited April 12, 2025 by Merkyrrie

[Doodle Monster]

Got it! it makes sense; the onequip and unequip functions won't know what OndoingWork is unless the function is above them

[Doodle Monster]

Okay, So I moved the function and tested it; and the sanity drain is working! Just not the FX

[Doodle Monster]

@Merkyrrie I assume I have to specify the location of the FX somehow? I don't think the code for the attack will work

[Merkyrrie]

4 hours ago, Doodle Monster said:

@Merkyrrie I assume I have to specify the location of the FX somehow? I don't think the code for the attack will work

The same code should work, just use 'data.target' in place of 'target' for example 'target.Transform:GetWorldPosition()' becoming data.target.Transform:GetWorldPosition()

Data.target in this case is the instance of the rock/tree being worked.

[Doodle Monster]

Awesome! I'll give it a test then get back to you.

[Doodle Monster]

I pulled it up ingame and gave it a test! Sanity drain is definitely working but the FX isn't showing up after I added the 'data.target'

I'm not sure If I need the math at the end that transforms the FX either here's my function and prefab file.

local function OnDoingWork(owner, data)

    -- From Wolfgang's prefab

    if data ~= nil and data.target ~= nil then

        local workable = data.target.components.workable

        if workable ~= nil then

            local work_action = workable:GetWorkAction()

            if work_action ~= nil then



                local fx_prefab = "shadow_despawn" and



                    owner.components.sanity:DoDelta(-.5 * TUNING.BATBAT_DRAIN)



                    if fx_prefab ~= nil then

                        local fx = SpawnPrefab(fx_prefab)

                        local x, y, z = data.target.Transform:GetWorldPosition()

                        local radius = data.target:GetPhysicsRadius(.5)

                        local angle = (inst.Transform:GetRotation() - 90) * DEGREES

                        fx.Transform:SetPosition(x + math.sin(angle) * radius, 0, z + math.cos(angle) * radius)

                    end

                -- Spawn FX and lower sanity code would go here

            end

        end

    end

end

woven_axe.lua

[Doodle Monster]

@Merkyrrie

[Baguettes]

Put fx.Transform:SetPosition(x, y, z) under your local x, y, z, that may work.

[Merkyrrie]

1 hour ago, Baguettes said:

Put fx.Transform:SetPosition(x, y, z) under your local x, y, z, that may work.

Yeah I'm not sure if the math is actually necessary in this instance or not, however,

 local fx_prefab = "shadow_despawn" and

Remove the "and" here as its causing it to actually make fx_prefab nil here, as well as,

local angle = (inst.Transform:GetRotation() - 90) * DEGREES

"inst" here should be "owner" instead.

[Baguettes]

1 hour ago, Merkyrrie said:

Yeah I'm not sure if the math is actually necessary in this instance or not, however,

All prefabs from SpawnPrefab defaults to 0, 0, 0 if you don't specify where it should go.

[Merkyrrie]

7 minutes ago, Baguettes said:

All prefabs from SpawnPrefab defaults to 0, 0, 0 if you don't specify where it should go.

This is correct, the Transform:SetPosition is necessary. I just meant the math applied to the workable's x,y,z in this SetPosition might not be necessary

[Doodle Monster]

It works now! Thanks for the help; Now I just need to do the same thing with the pickaxe which I assume would be exactly the same.
